Technische Spezifikationen
Bauart
Rack-montierbar, 1U
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Datenübertragungsrate (Ethernet)
1 Gbps
Leistungsmerkmale
VLAN
4000 IDs / 1005 VLANs
Produktzertifizierungen (IEEE)
802.1D Spanning Tree Protocol (STP)
ja
802.1Q Tagged VLAN (frame tagging on all ports when VLANs are enabled)
ja
802.1p Class of Service (CoS) prioritization
ja
802.1s Multiple STP (MSTP)
ja
802.1w Rapid STP (RSTP)
ja
802.1x port-based authentication
ja
802.3 10BASE-T Ethernet
ja
802.3ab 1000BASE-T copper twisted pair Gigabit Ethernet
ja
802.3ad Link Aggregation Control Protocol
ja
802.3u 100BASE-TX Fast Ethernet
ja
802.3x Full-duplex Flow Control
ja
802.3z 1000BASE-LX long range fiber optics Gigabit Ethernet
ja
802.3z 1000BASE-SX short range fiber optics Gigabit Ethernet
ja
802.3at Power oer Ethernet + (PoE+)
ja
Anschlüsse
Netzwerk - PoE+ - RJ-45
48
Verwaltung - Ethernet - RJ-45
1
Verwaltung - RS-232 - Mini-USB
1
Verwaltung - RS-232 - RJ-45
1
Netzwerkfunktionen
Jumbo frame size (in byte)
9216
Module
Installierte Lizenzen
Hinweis
Besonderheit
ACHTUNG - Netzkabel sind im Lieferumfang nicht enthalten.
